Building an Interactive Data Structures & Algorithms Workbook with TypeScript

After building a successful Python-based DSA learning platform, I wanted to create a version that runs entirely in the browser—no backend, no server costs, just pure client-side TypeScript. The result is an interactive workbook featuring 50+ algorithm implementations with visualizations, complexity analysis, and real-world use cases.

Live Demo: https://ianlintner.github.io/typescript_dsa/
Source Code: https://github.com/ianlintner/typescript_dsa

Why TypeScript for Algorithms?

While Python is the go-to language for algorithm education, TypeScript offers unique advantages for interactive learning platforms:

• Type Safety: Catch errors at compile-time rather than runtime
• Browser Native: No compilation to WASM, runs directly in V8
• Rich Tooling: VS Code, ESLint, and Prettier provide excellent DX
• Static Deployment: Zero infrastructure costs with GitHub Pages or Azure Static Web Apps
• Performance: V8's JIT compilation rivals Python for algorithm execution

The trade-off? TypeScript's verbosity compared to Python's conciseness. But for a learning platform where clarity matters more than brevity, explicit types enhance understanding.

Architecture: Pure Static with React + Vite

The application architecture prioritizes simplicity and developer experience:

// Stack
- React 18 (UI components)
- TypeScript 5 (type safety)
- Vite (build tooling)
- Vitest (unit testing)
- GitHub Actions (CI/CD)
- Azure Static Web Apps / GitHub Pages (hosting)

Why Vite Over Create React App?

Vite's esbuild-powered dev server starts in milliseconds versus CRA's webpack taking 30+ seconds. For an educational project where contributors iterate rapidly, this matters:

• Dev Server: ~200ms cold start vs ~30s
• HMR: Instant vs 1-3s per change
• Build Time: ~5s vs ~45s for production
• Bundle Size: Tree-shaking removes unused algorithms

Static-First Design

Every feature is designed to work without a backend:

// No server-side rendering
// No API routes
// No database calls
// No authentication (public learning resource)

// Instead:
- Algorithm implementations in pure functions
- Visualizations using Canvas API
- State management via React hooks
- Routing via React Router (client-side)

This enables deployment to any static host with zero operational overhead.

Algorithm Categories & Implementations

The workbook organizes 50+ algorithms into eight categories:

🚀 Sorting Algorithms (8)

• QuickSort, MergeSort, HeapSort
• Bubble, Insertion, Selection, Counting, Radix

Design Decision: Each algorithm includes multiple implementations (iterative, recursive, optimized) to demonstrate trade-offs between readability and performance.

🔍 Searching Algorithms (6)

• Binary Search (iterative & recursive)
• Linear Search, Jump Search, Interpolation Search
• Exponential Search, Ternary Search

Key Feature: Interactive visualizations show how different search strategies behave with various data distributions.

🕸️ Graph Algorithms (8)

• BFS, DFS, Dijkstra's Shortest Path
• Bellman-Ford, Floyd-Warshall
• Kruskal's MST, Prim's MST, Topological Sort

Implementation Note: Graph representations use adjacency lists for space efficiency (O(V + E) vs O(V²) for matrices).

🧩 Dynamic Programming (8)

• Fibonacci (memoization & tabulation)
• Knapsack (0/1 & unbounded)
• Longest Common Subsequence
• Edit Distance, Coin Change, Matrix Chain Multiplication

Teaching Approach: Each DP problem includes:

1. Naive recursive solution (to show exponential complexity)
2. Top-down memoized version
3. Bottom-up tabulation
4. Space-optimized variant when applicable

🏗️ Data Structures (7)

• Binary Search Tree, AVL Tree, Red-Black Tree
• Min/Max Heap, Trie, Segment Tree, Union-Find

Interactive Component: Visual tree builders let users insert/delete nodes and see balancing operations in real-time.

📝 String Algorithms (5)

• KMP Pattern Matching
• Rabin-Karp, Boyer-Moore
• Longest Palindromic Substring
• Manacher's Algorithm

🎯 Problem Patterns (6)

• Two Pointers, Sliding Window
• Fast & Slow Pointers
• Backtracking, Greedy Algorithms
• Divide & Conquer

🔢 Math Utilities (15+)

• Prime generation (Sieve of Eratosthenes)
• GCD, LCM, Modular exponentiation
• Factorial, Permutations, Combinations

Code Quality & Testing

Every algorithm includes:

// 1. Type-safe implementation
export function quickSort<T>(
  arr: T[],
  compareFn: (a: T, b: T) => number = defaultCompare,
): T[] {
  // Implementation...
}

// 2. Comprehensive unit tests
describe("quickSort", () => {
  it("sorts numbers in ascending order", () => {
    expect(quickSort([3, 1, 4, 1, 5])).toEqual([1, 1, 3, 4, 5]);
  });

  it("handles edge cases", () => {
    expect(quickSort([])).toEqual([]);
    expect(quickSort([1])).toEqual([1]);
  });

  it("works with custom comparators", () => {
    const desc = (a: number, b: number) => b - a;
    expect(quickSort([1, 2, 3], desc)).toEqual([3, 2, 1]);
  });
});

// 3. Big-O complexity documentation
/**
 * Quick Sort
 *
 * Time Complexity:
 * - Best: O(n log n)
 * - Average: O(n log n)
 * - Worst: O(n²) - when pivot is consistently min/max
 *
 * Space Complexity: O(log n) - recursion stack
 *
 * Stability: No
 * In-place: Yes (can be implemented in-place)
 */

Testing Strategy

• Unit Tests: Vitest for algorithm correctness
• Type Tests: TypeScript's strict mode catches type errors
• Visual Tests: Manual verification of visualizations
• CI Pipeline: GitHub Actions runs tests on every PR

Algorithm Visualizer

The interactive visualizer is the platform's killer feature:

// Visualizer Architecture
1. Algorithm Selection → Choose from 50+ algorithms
2. Input Configuration → Provide test data
3. Step-by-Step Execution → Watch algorithm progress
4. Performance Metrics → See time/space complexity in action

Technical Implementation:

• Canvas API for rendering (better performance than SVG for animations)
• Request Animation Frame for smooth 60fps updates
• Web Workers for algorithm execution (keeps UI responsive)
• Configurable speed controls (0.25x to 4x)

Example: Visualizing QuickSort

interface VisualizationStep {
  array: number[];
  pivotIndex: number;
  comparisons: [number, number][];
  swaps: [number, number][];
  message: string;
}

function* quickSortVisualization(arr: number[]): Generator<VisualizationStep> {
  // Yield visualization steps during sorting
  // Canvas updates after each yield
}

Big-O Reference Guide

The built-in complexity guide provides quick reference:

Algorithm	Best	Average	Worst	Space
QuickSort	O(n log n)	O(n log n)	O(n²)	O(log n)
MergeSort	O(n log n)	O(n log n)	O(n log n)	O(n)
Binary Search	O(1)	O(log n)	O(log n)	O(1)
DFS/BFS	O(V + E)	O(V + E)	O(V + E)	O(V)

Interactive Features:

• Sort table by any complexity metric
• Filter by algorithm category
• Compare multiple algorithms side-by-side

Deployment: Static Web Apps

The application deploys to multiple platforms:

GitHub Pages (Primary)

# .github/workflows/deploy.yml
name: Deploy to GitHub Pages

on:
  push:
    branches: [main]

jobs:
  build-deploy:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - uses: actions/setup-node@v3
        with:
          node-version: "18"
      - run: npm ci
      - run: npm run build
      - uses: peaceiris/actions-gh-pages@v3
        with:
          github_token: ${{ secrets.GITHUB_TOKEN }}
          publish_dir: ./dist

Cost: $0/month (GitHub Pages is free for public repos)

Azure Static Web Apps (Alternative)

// staticwebapp.config.json
{
  "routes": [
    {
      "route": "/*",
      "serve": "/index.html",
      "statusCode": 200
    }
  ],
  "navigationFallback": {
    "rewrite": "/index.html"
  },
  "mimeTypes": {
    ".json": "application/json"
  }
}

Benefits:

• Global CDN distribution
• Automatic PR previews
• Custom domains with free SSL
• Staging slots

Cost: Free tier includes 100GB bandwidth/month

Performance Optimizations

Code Splitting

// Lazy load algorithm categories
const SortingAlgorithms = lazy(() =>
  import('./categories/SortingAlgorithms')
);
const GraphAlgorithms = lazy(() =>
  import('./categories/GraphAlgorithms')
);

// Route-based splitting
<Route path="/sorting" element={
  <Suspense fallback={<Loading />}>
    <SortingAlgorithms />
  </Suspense>
} />

Result: Initial bundle ~150KB, lazy chunks ~20-40KB each

Tree Shaking

Vite's Rollup-based bundler automatically removes unused algorithms:

// User only visits sorting page
// → Graph, DP, and string algorithms never loaded
// Saves ~200KB of JavaScript

Asset Optimization

• SVG icons inlined when <5KB
• Images served as WebP with PNG fallback
• Fonts subseted to include only used glyphs
• Gzip/Brotli compression on CDN

Lighthouse Score: 98/100 (Performance)

Future Enhancements

Planned Features

1. Leetcode Integration: Map algorithms to relevant problems
2. Code Playground: Live editor to modify algorithms
3. Performance Benchmarks: Compare implementations with real metrics
4. Mobile App: React Native version with offline support
5. Collaborative Features: Share custom test cases via URL params

Technical Debt

• Replace Canvas with WebGL for better visualization performance
• Add Web Workers for all algorithm execution (not just visualizer)
• Implement service worker for offline-first experience
• Add internationalization (i18n) for non-English speakers

Lessons Learned

What Worked

1. TypeScript Everywhere: Type safety caught countless bugs during development
2. Static-First: Zero operational overhead, infinite scalability
3. Vite: Incredible DX improvement over previous tooling
4. Incremental Development: Ship algorithm categories independently

What I'd Do Differently

1. Start with Visualizations: Built algorithms first, visualizations later—should've done both together
2. Better Testing Utilities: Need snapshot tests for visualization states
3. Earlier Performance Testing: Discovered some O(n²) rendering only after building 20+ visualizations
4. Documentation First: Writing docs after implementation is harder than alongside

Comparison: TypeScript vs Python DSA

Aspect	TypeScript Version	Python Version
Performance	V8 JIT ~equal to CPython	CPython interpreter
Deployment	Static files, free hosting	Requires server (Flask/Django)
Type Safety	Compile-time checking	Runtime only (without mypy)
Learning Curve	Steeper (types + async)	Gentler for beginners
Interactivity	Browser-native (Canvas/WebGL)	Requires matplotlib/pygame
Cost	$0/month	$5-20/month (hosting)

When to Use TypeScript:

• Building public learning resources (static = free)
• Need browser-based interactivity
• Team already uses TypeScript
• Prioritize type safety over conciseness

When to Use Python:

• Teaching absolute beginners
• Need NumPy/SciPy for advanced math
• Jupyter notebooks for exploration
• Rapid prototyping over production readiness

Try It Yourself

The platform is live and free to use:

🎬 Interactive Demo: https://ianlintner.github.io/typescript_dsa/
📊 Algorithm Visualizer: Try the visualizer
📈 Big-O Reference: Complexity guide
💻 Source Code: GitHub Repository

Conclusion

Building a browser-based DSA learning platform with TypeScript demonstrates the power of modern web technologies for educational tools. By prioritizing static deployment, type safety, and interactive visualizations, we created a resource that's:

• Free to host (GitHub Pages)
• Fast to load (<200ms initial render)
• Easy to maintain (TypeScript catches bugs)
• Globally accessible (CDN distribution)

Whether you're preparing for technical interviews, teaching algorithms, or just exploring computer science fundamentals, I hope this project serves as both a learning resource and a reference implementation for building educational web applications.

Next Steps:

1. Explore the live demo
2. Try the algorithm visualizer
3. Contribute on GitHub
4. Check out the Python version for comparison

---

Have feedback or want to contribute? Open an issue or PR on GitHub. Let's make algorithm education more accessible together.
